Certification : ISO, CE
Model NO. : HT-S50-24M
Application : All Fields
Condition : New
Material : Monocrystalline Silicon
Application Level : Class a
Working Temperature (ºC) : -40~+85
Rated Battery Working Temperature : 45±2ºC
Fire-Protection Rating : Class C
Junction Box : Protection Grade IP68
Cable : 4.0mm2,900mm
Component Border : Anodic Oxidation
Transport Package : Wooden Box
Trademark : htonetech
Origin : China
Supply Ability : 50000pieces/Year
Shipping Cost : To be negotiated| Freight Cost Calculator
After-sales Service : Yes
Warranty : 25 Years
Number of Cells : 1
Solar photovoltaic (PV) panels have a wide range of applications across various sectors. Here are some common applications of solar PV panels:
Residential Solar Power: Solar panels are commonly installed on residential rooftops to generate electricity for homes. They can power household appliances, lighting, heating and cooling systems, and other electrical devices. Excess energy can be fed back to the grid or stored in batteries for later use.



Solar Panel solar module 150W 200w 250W 275W 300W 330W 430W 450W Solar PV Solar Panel Kits 5kw High Quality! Solar Energy PV Power | Model | Peak power(WP) | Peak Voltage(V) | Peak Current(A) | Short circuit current (A) | Open circuit voltage (V) | Size |
| HT-S150-24M | 150 | 18 | 8.33 | 8.99 | 22.5 | 1480X670X35 |
| HT-S200-24M | 200 | 36 | 5.56 | 6.01 | 44.8 | 1580X808X35 |
| HT-S250-24M | 250 | 30 | 8.33 | 8.99 | 36.8 | 1640X992X40 |
| HT-S275-24M | 275 | 30 | 9.17 | 9.81 | 37.2 | 1640X992X40 |
| HT-S300-24M | 300 | 30 | 10 | 10.7 | 37.2 | 1650X992X35 |
| HT-S330-24M | 330 | 36 | 9.17 | 9.81 | 44.64 | 1956X992X40 |
| HT-S430-24M | 430 | 40.3 | 10.67 | 11.22 | 48.7 | 2102X1040X35 |
| HT-S450-24M | 450 | 41.0 | 10.98 | 11.53 | 49.6 | 2102X1040X35 |
| Maximum power Pmp temperature coefficient | =-0.35%/ºC | |||||
| The open-circuit voltage Voc | =-0.28%/ºC | |||||
| temperature coefficient Short-circuit current | 0.048%/"ºC | |||||
| Component border | anodic oxidation | |||||
| Junction box | Protection grade IP68 | |||||
| cable | 4.0mm2,900mm | |||||
| working temperature (ºC) | -40~+85 | |||||
| Application level | Class A | |||||
| fire-protection rating | Class C | |||||
| Rated battery working temperature | 45±2ºC | |||||




|
|
IP68 Solar Photovoltaic Panel Polycrystalline Monocrystalline Silicon Images |
